SPAN Panel MAIN 32 Smart Electrical Panel (1-00800) - Clearance / Open Box
SPAN Panel MAIN 32
World's smartest electrical panel with circuit level energy monitoring and control offering unprecedented cost saving home energy insights.
- Customizable, flexible, whole-home backup when paired with battery storage - provide 40% longer backup duration
- Pre-installed energy management system (EMS) software, SPAN PowerUp, for avoiding electrical service upgrades
- Free over-the-air updates for an always improving homeowner experience
- Category defining safety as the only electrical panel with Power Control System (PCS) listing and certification
Electrical
- Integrated grid disconnect relay
- Revenue accurate energy monitoring
- 100 - 200A main breaker
- 225A bussing
Installation
- Indoor and outdoor rated
- Surface or flush-mount
- Compatible with standard 1 breakers
Connectivity
- Ethernet, WiFi, Cellular
- Free over-the-air updates
Intuitive Control
SPAN goes beyond monitoring with the SPAN Home app for real-time control and energy insights to bring your home energy to life. Combined with battery storage, SPAN gives homeowners the power to choose and change backup priorities whenever they want.
Compatibility
SPAN Panel MAIN 32 is only compatible with MAIN 32 Panels for multi-panel installations.
Energy Management System (EMS)
Every SPAN Panel comes pre-installed with PowerUp. PowerUp is an Energy Management System (EMS) that enables homeowners to install high-power electric upgrades like heat pumps, hot tubs, and EV chargers without exceeding their electrical service capacity.
Homeowners can set preferences for what PowerUp manages during peak-load events in the SPAN Home App, with minimal-to-no disruption experienced.
Technical Specifications:
Controllable circuit spaces: 32
Voltage: 120/240V split phase
Grid frequency: 60Hz
Main breaker rating: 100 - 200A
Bus bar rating: 225A
Max branch circuit size: 90A
Feed-thru lugs: Yes
AC metering: Revenue accurate
Max input short circuit current: 22kA
Energy management system: SPAN PowerUp capable, Backup overload protection
Certifications: UL 67, UL 916, UL 869A, UL 3141 [PCS]
Enclosure rating: NEMA 3R (Indoor and outdoor)
Datasheet
Original: $3,299.00
-65%$3,299.00
$1,154.65
