McIntosh C12000 2-Channel Solid State and Vacuum Tube Preamplifier

Unlock the Ultimate in Sound Performance with McIntosh C12000 2-Channel Preamplifier

Immerse yourself in the pinnacle of audio quality with the McIntosh C12000 2-Channel Preamplifier. This revolutionary preamplifier combines cutting-edge technology and precision engineering to deliver an unparalleled audio experience. Whether you're a seasoned audiophile or a music enthusiast, the C12000 will redefine your expectations of sound.

McIntosh C12000 Key Features:

• Hybrid Drive™ Technology: Integrating the best of vacuum tubes and solid-state technology for exceptional sound performance.
• Two-Chassis Design: Absolute separation of audio and control sections for pure and uncompromised sound reproduction.
• 12 Analog Inputs: Including 2 configurable phono inputs, offering flexibility for your turntable(s), cartridge(s), and vinyl collection.
• Dual Mono Operation: Achieve ultimate stereo separation and sonic purity with electrically and mechanically isolated left and right channels.
• Vacuum Tube and Solid State Output: Choose between vacuum tube or solid-state output based on your musical preference and system configuration.

McIntosh C12000 Specifications:

• Number of Channels: 2
• Total Harmonic Distortion: High Level: 0.005%, Phono: 0.05%
• Frequency Response: +0, -0.5dB from 20Hz to 20kHz, +0, -3dB from 10Hz to 100kHz
• Maximum Volts Out (Balanced / Unbalanced): 20V RMS / 10V RMS
• Sensitivity High Level (Balanced / Unbalanced): 900mV / 450mV
• Sensitivity Phono (Moving Coil): 0.25 – 2.5mV
• Sensitivity Phono (Moving Magnet): 5 – 10mV
• Signal To Noise Ratio: High Level: 107dB, Moving Coil: 79dB, Moving Magnet: 83dB
• Voltage Gain: High Level: 15dB, Moving Coil: 58 – 64dB, Moving Magnet: 40 – 46dB

Connectivity:

• Balanced Input: 6
• Unbalanced Input: 4
• Phono Input Moving Coil: Up to 2 (configurable)
• Phono Input Moving Magnet: Up to 2 (configurable)
• Headphone Output: 1/4" High Drive with Headphone Crossfeed Director (HXD®)

Control and Customization:

• Tone Controls: No
• RS232 Control Input: Yes
• Power Control Output: 1 Main, 2 Output, 4 Trigger
• Selectable Headphone Impedances: 16 ohms - 40 ohms, 40 - 150 ohms, 150 - 600 ohms
• Home Theater PassThru: Yes

General Specifications:

• Multi-Chassis or Single: Multi-Chassis (C12000C plus C12000ST)
• Vacuum Tube or Solid State: Both (user selectable)
• Power Consumption (On): 75 watts

Weights & Dimensions:

• Unit Dimensions (W x H x D): Each module: 17.5" x 6" x 18"
• Unit Weight: C12000C: 27 lbs, C12000ST: 25 lbs
• Shipping Weight: C12000C: 42 lbs, C12000ST: 40 lbs
